GEALAN LINEAR
Fabricated By VENTANA
Performance in Profile.
VENTANA USA is proud to introduce GEALAN, an innovative system provider for PVC window and door profiles built for durability, comfort, and versatility.
GEALAN window systems support clear architectural intentions. Slim profiles, efficient chambering, and durable surface technologies enable controlled daylighting, stable function, and consistent thermal comfort in both residential and multi-unit applications,
The modern aluminum look in thermally superior uPVC.
Highlights.
• Slim installation depth in a linear design
• Narrow visible widths for more light in the interior
• High stability thanks to steel stiffeners
• Solutions for windows, French doors and front doors
• Angular 90-degree look on both the outside and inside
• Perfect for renovations, refurbishments and new builds – lasting value and durable
• Extensive decorative foil range, from smooth to ultra-matt decors
• Real Wood® – decorative wood foils for a customized look and feel
• Sustainable thanks to a recycled core
Benefits of Gealan-Linear.
GEALAN-LINEAR doesn’t just look great; it’s built to perform. Discover the key benefits that set this system apart.
Design
Clean and simple design language, reflecting the architectural trend towards straight-lined, angular window designs.
Versatility
A comprehensive product range from the outset, encompassing windows, doors, and sliding solutions, providing a complete system for diverse project needs.
Performance
Innovative system construction, meticulously engineered to meet user demands and exceed expectations.
Aluminum Looks
The angular design gives the frame an aluminum look, giving it a high-class aesthetic.
Thermal Insulation
Achieve top values in the 3 in segment with a U-Factor up to 0.14 Btu/h·ft²·°F, ensuring exceptional energy efficiency.
Efficiency
Optimized profile constructions and innovative details ensure a high degree of compatibility between profiles and accessories, simplifying installation and maximizing performance.
Five Standard Color Options
White
Sandstone
Anthracite Grey
Ash
Black
Aluminum Looks. Passive House Performance.
01
Looks like aluminum
Square edges, a flush sash, and narrow sightlines create the contemporary look North American architects are specifying today.
02
Sized like aluminum
Steel-reinforced frames are available up to 137" in width and 137" in heigh-suitable for windows, storefronts, and full-heigh residential elevations.
03
Performs like Passive House
Three-gasket sealing with U-factors as low as 0.14-PHIUS recommended for cold climates (Climate Zones 5A/5B)
Three independent seals-tested to AW-class air and water tightness
01
Exterior Gasket
Outer weather seal at the sash-to-frame line-the first barrier against wind-driven rain and airborne moisture.
02
Center Gasket
Middle seal creates a pressure-equalized drainage chamber, isolating the outer weather zone from the warm interior.
03
Interior Gasket
Inner air-tightness seal-protects indoor comfort and condensation performance.
Project Inspiration
View Real Projects Using Gealan Profiles.
Performance above premium vinyl windows.
air leakage
3x Tighter Envelope
<0.10
cfm/sq.ft.
3x tighter
Typical vinyl windows: 0.20-0.30 cfm/sq.ft (NFRC default)
design pressure
Above the aluminum range
105
psf
+
-
3.5x builder-grade
Builder-grade vinyl windows: +/- 15-30 psf
Premium vinyl windows: +/- 30-40 psf
Thermally-broken aluminum windows: +/- 50-90 psf
water penetration
Tested to the NAFS ceiling
15.04
psf
Max NAFS test pressure
Builder-grade vinyl windows: 2.86-6 psf
2.5-5x higher water-test pressure
